Mini Solar Pump Inverter 0.75-4KW PV Pump Inverter VFD

CT112M-2T-0.7~2.2G

Input specification

Maximum Input PV Voltage

(PV Open-Circuit Voltage)

450VDC

320~370VDC(Vmp)

388~450VDC (VOC)

Input specification (Grid or backup generator input)

Input voltage

1PH 220V(-15%～30%)

Output specification

Rated output voltage

3PH 220V

Output frequency

0～500.00Hz(default: 0～50.00Hz)

Fault protection

Built-in Protection

Protection of light load, over-current, over-voltage, output phase-lose, under-load, under-voltage, short circuit, overheating, water pump run dry etc.

CT112M-4T-0.7~4G

Input specification (PV Input)

Maximum Input DC Voltage

(PV Open-circuit Voltage)

780VDC

Recommended MPPT Voltage Range

540~630VDC (Vmp)

Recommended Input Operation Voltage

670~780VDC (VOC)

Input specification (Grid or backup generator input)

Input Voltage Range

Three phase 380VAC(-15%～30%)

Output specification

Rated output voltage

3PH 380VAC

Output frequency

0～500.00Hz(Default 0～50.00Hz)

Fault protection

Built-in Protection

Protection of light load, over-current, over-voltage, output phase-lose, under-load, under-voltage, short circuit, overheating, water pump run dry etc.

Keypad display

LED display

Highlight LED digital tube displays the inverter information

LCD display

LCD displays inverter information

Others

Application Site

No direct sunshine, no dust, corrosive gas, combustible gas, oil mist, steam, dripping or salinity etc.

Altitude

0～2000m, Derated use above 1000m,per100m, the rated output current decrease 1%.

Environment Temperature

-10℃～50℃ (Environment Temperature be 40℃～50℃, please keep derated use.)

Humidity

5～95%,non-condensation

Vibration

less than 5.9 m/s2(0.6g)

Storage Temperature

-20℃～+70℃

Efficiency

Rated Power Run≥93%

Installation

Wall or rail mounting

Cooling

Forced Air Cooling
